🔥 600KW Industrial Air Heater | High-Temperature Air Heating Solution
Product Overview
The 600KW Industrial Air Heater is designed for high-temperature industrial applications, delivering reliable and efficient air heating up to 500°C. Operating at 380 V, it features multiple tubular electric heating elements with magnesium oxide (MgO) insulation inside a robust, compact housing, ensuring maximum thermal transfer, energy efficiency, and electrical safety.
Ideal for space-constrained industrial environments, this heater combines high performance with durable construction, making it suitable for a wide range of industrial heating, drying, and processing applications.
Key Benefits for Buyers
✅ High-Capacity Heating – 600KW output for demanding industrial processes.
✅ Extreme Temperature Capability – Operates up to 500°C for high-temperature applications.
✅ Energy-Efficient Operation – High thermal efficiency reduces electricity costs.
✅ Rapid Heating Response – Quick warm-up improves process efficiency.
✅ Compact Footprint – Space-saving design for easy installation.
✅ Customizable Solutions – Non-standard configurations available.
✅ Durable Construction – Engineered for long-term industrial use.
Product Features
-
Power Rating: 600KW high-capacity output
-
Maximum Temperature: 500°C operating capability
-
Input Voltage: 380V industrial standard
-
Heating Elements: Multiple tubular design with MgO insulation
-
Thermal Efficiency: High-efficiency heat transfer
-
Heating Speed: Rapid warming technology
-
Construction: Compact, durable housing with deflector plates
-
Customization: Non-standard designs available for specialized applications
Technical Specifications
| Parameter |
Specification |
| Product Name |
600KW Industrial Air Heater |
| Power Output |
600 KW |
| Maximum Temperature |
500°C |
| Input Voltage |
380V |
| Heating Element |
Tubular electric heating with MgO insulation |
| Thermal Efficiency |
High efficiency rating |
| Heating Response |
Rapid warming capability |
| Construction |
Robust housing with deflector plates |
| Customization |
Non-standard designs available |
Working Principle
The heater uses tubular electric heating elements containing high-temperature resistance wires sealed in metal tubes. Crystalline magnesium oxide powder fills the voids, providing excellent insulation and efficient heat conduction.
When powered, the resistance wires generate heat that transfers through the MgO insulation to the tube surfaces. Air passing over these heated surfaces absorbs thermal energy, reaching temperatures up to 500°C. Deflector plates ensure uniform air distribution across all heating elements for maximum heating efficiency.
Applications & Case Scenarios
-
🏭 Industrial Processing – High-temperature air for manufacturing systems
-
⚙️ Heat Treatment Systems – Air heating for metallurgical and material processing
-
💨 Drying Applications – Intensive drying requiring high-temperature air
-
🧪 Chemical Processing – Process air heating for chemical manufacturing
-
⚡ Power Generation – Air pre-heating and process heating solutions
-
🔧 Custom Industrial Applications – Tailored solutions for specialized high-temperature needs
Request a Custom Quote
Provide your temperature requirements, airflow specifications, installation environment details, and any special customization needs. Our engineering team will design a tailored 600KW industrial air heater solution for your operation.
