Electric Heating Thermal Oil Boiler — 10–4200 kW

This electric heating thermal oil boiler from Ruiyuan delivers clean, high-efficiency process heat for reactors, dryers, rollers and industrial ovens. Custom power output from 10 kW to 4200 kW, electric heating, PLC/PID control, solid-state temperature regulation and premium construction. Thermal efficiency ≥98% and standard 380 V / 50 Hz (customisable).

Get Your Customised Product

⚡ Electric Heating Thermal Oil Boiler — High-Efficiency Industrial Heating Solution

🔍 Product Overview

The Ruiyuan Electric Heating Thermal Oil Boiler delivers stable, homogeneous heat through heat-transfer oil circulated by a high-temperature pump.
Using pure electric heating, it eliminates combustion, making it clean, safe, and easy to install.

With PLC/PID intelligent temperature control and solid-state regulation (typical accuracy ±1°C), the system ensures precision, efficiency, and safety across a wide range of industrial applications.

💡 Key Benefits for Buyers

✅ Clean Electric Heating — No combustion, no emissions, and simplified installation process.
✅ High Thermal Efficiency — ≥98% efficiency ensures minimal energy loss and reduced operating costs.
✅ Precision Control — PLC/PID + solid-state regulation maintains ±1°C accuracy for consistent product quality.
✅ Modular Design — Compact, easy to integrate, and simple to maintain on-site.
✅ Customizable Build — Flexible capacity, materials, and layout to match non-standard industrial processes.

⚙️ Product Features

Feature Specification / Advantage
Power Range 10–4200 kW (Customizable)
Heating Method Electric heating (flange heaters or seamless tube elements)
Control System PLC/PID + solid-state/silicon temperature regulation
Structure All-welded boiler body (stainless or carbon steel); custom size options
Thermal Efficiency ≥98%
Temperature Accuracy ±1°C (PID precision)
Standard Voltage 380 V / 50 Hz (Customizable)
Accessories Flange heaters, centrifugal/shield pumps, thermistor sensors, ceramic-fiber insulation, cast-steel oil ports

📊 Technical Specifications

Parameter Specification
Product Name Electric Heating Thermal Oil Boiler
Power Output 10–4200 kW (Customizable)
Heating Method Electric heating (flange or seamless tube elements)
Thermal Efficiency ≥98%
Temperature Control PLC/PID; solid-state/silicon regulated; ±1°C accuracy
Structure / Material All-welded body; stainless or carbon steel
Standard Voltage 380 V / 50 Hz (Customizable)
Typical Applications Reactors, dryers, rollers, asphalt tanks, hot presses, tunnel ovens, pharmaceuticals, building materials
Control & Monitoring Remote/DCS support, thermistor sensors, optional explosion-proof gauges

🏭 Applications & Case Scenes

✅ Dryer and Roller Lines — Continuous production with stable heat supply.
✅ Industrial Ovens & Tunnel Processes — Long-length heating with consistent oil circulation.
✅ Reactors & Tank Heating — Precise oil temperature control for chemical and materials processing.
✅ Hot-Press & Finishing Lines — Uniform heat distribution improves quality and production efficiency.

🌟 Why Choose Ruiyuan

  • Combustion-free, eco-friendly operation

  • Proven 98%+ energy efficiency

  • Accurate ±1°C temperature regulation

  • Custom engineering for unique process needs

  • Safe, closed-loop electric heating system

📞 Request a Custom Quote

To receive your tailored engineering solution, please share your process details:

  • Required Temperature Range

  • Heat Duty (kW)

  • Oil Type

  • Footprint & Installation Constraints

📩 Email: sabbir@cnryan.com
📱 WhatsApp: +86-19106101572

Ruiyuan — Precision Electric Heating Systems for Modern Industry.
