🔥 Thermal Oil Hot Air Circulation Oven | Precision Industrial Heating Equipment
Product Overview
The Thermal Oil Hot Air Circulation Oven is a high-performance industrial heating system designed to deliver precise and stable temperatures from 80°C to 300°C. By using heat transfer oil as the heating medium, it provides uniform and efficient heat distribution for a variety of manufacturing and thermal processing applications.
Built with a SUS304 stainless steel inner chamber and A3 cold plate exterior, this oven ensures durability and resistance to corrosion. Its aluminum silicate fiber insulation layer guarantees superior heat retention and energy savings. The low-pressure, liquid-phase operation ensures maximum safety, maintaining temperature accuracy within ±1°C, ideal for demanding industrial environments.
Key Benefits for Buyers
✅ Enhanced Operational Safety – Low-pressure system (1/70–1/80 of steam pressure) minimizes explosion risk.
✅ Precision Temperature Control – Maintains ±1°C accuracy for consistent production quality.
✅ Superior Thermal Efficiency – 40–50% higher heat utilization than steam-based systems.
✅ Water-Free Technology – No water usage or treatment equipment needed.
✅ Energy-Saving Performance – Lower operating costs with no freeze protection requirements.
✅ Stable & Reliable Heating – Large oil volume prevents sudden temperature drops.
✅ Long Service Life – Stainless steel construction ensures durability under continuous operation.
Product Features
-
Temperature Range: 80–300°C
-
Temperature Accuracy: ±1°C precision control
-
Inner Material: SUS304 stainless steel chamber
-
Insulation: 8–10 mm aluminum silicate fiber layer
-
Heating Medium: Thermal oil (liquid-phase heat transfer)
-
Oil Flow Rate: 2.3–2.7 m/s circulation speed
-
Safety System: Full monitoring and control protection
-
Customization: Available in various capacities and configurations
Technical Specifications
| Parameter |
Specification |
| Product Name |
Thermal Oil Hot Air Circulation Oven |
| Operating Temperature |
80–300°C |
| Temperature Control Accuracy |
±1°C |
| Inner Material |
SUS304 stainless steel |
| Exterior Material |
A3 cold plate |
| Insulation Thickness |
8–10 mm aluminum silicate fiber |
| Heating Medium |
Thermal oil |
| Oil Circulation Speed |
2.3–2.7 m/s |
| Maximum Oil Temperature |
320°C |
Working Principle
This thermal oil circulation oven functions through a closed-loop heat transfer system. Heated thermal oil circulates at 2.3–2.7 m/s, transferring heat through exchangers to maintain uniform chamber temperature.
A built-in forced air circulation distributes heat evenly, ensuring every part of the material receives equal thermal exposure. The large thermal oil capacity (up to 3 tons) provides remarkable stability, preventing sudden temperature changes and guaranteeing ±1°C precision across the oven’s entire range.
Applications & Industry Use Cases
-
🏭 Industrial Drying: Paint, coating, and surface finishing processes
-
🍞 Food Processing: Baking, drying, and sterilization
-
🧵 Textile Industry: Fabric drying and heat-setting applications
-
💊 Pharmaceutical Production: Controlled material drying and sterilization
-
⚗️ Chemical Processing: Thermal conditioning and moisture removal
-
💻 Electronics: Component curing and heat testing
-
🧪 Laboratory & R&D: Controlled environment thermal testing
Request a Custom Quote
Looking for a custom-designed Thermal Oil Hot Air Circulation Oven for your production line?
Tell us your temperature requirements, production volume, and available space, and our engineering team will create a tailored solution for your operation.
